The expansion of the LGR series of roller linear guide pairs can meet the needs of various customers for high rigidity rolling linear guide pairs, and this product contributes to improving the quality of machine tool processing surfaces.
The LGR85/LGR100 large and LGR15/LGR20 small roller linear guide pairs have been expanded in the product line of the LGR series roller linear guide pairs, inheriting the internal design structure of the LGR series, replacing steel balls with cylindrical rollers. The rollers are in line contact with the guide rails and sliders, and only form small elastic deformation when subjected to high loads, greatly improving the rigidity of the guide pairs< Br/>


LGR85/LGR100 Large Roller Linear Guide Pair


&Nbsp; LGR100 Roller Linear Guide Pair

&Nbsp;
&Radio; High load capacity
In the ultra-high load durability test, after running for 600KM, there was no fish scale peeling on the surface of the guide rail groove

&Nbsp;
&Radio; High rigidity
Replacing steel balls with rollers, the rollers are in line contact with the guide rail and slider, only forming small elastic deformation when subjected to high loads, greatly improving the rigidity of the guide rail pair

&Nbsp;
&Radio; Maximum speed of 80m/min, maximum acceleration of 2G
The main accessories are made of impact resistant materials, which can achieve high-speed movement

&Nbsp;
&Radio; The length of a single guide rail reaches 6000mm





LGR15/LGR20 Small Roller Linear Guide Pair
nine hundred and two
LGR20 roller linear guide pair (left), LGR15 roller linear guide pair (right)

&Nbsp;
&Radio; Fill the domestic gap
&Nbsp;
&Radio; High rigidity
In the static stiffness test, the stiffness of the LGR15 roller guide pair is more than 2.5 times that of the LGS15 ball guide
&Nbsp;
&Radio; Maximum speed up to 120m/min, maximum acceleration 3G
The main accessories are made of impact resistant materials, which can achieve high-speed movement
&Nbsp;
&Radio; Single guide rail length up to 4000mm
